Product Description
Use the probe with the compatible testo multifunction measuring instrument (please order separately) to determine CO2 concentration, air humidity and air temperature. Wet bulb temperature, dew point and absolute humidity are calculated at the same time.
CO2 probe with Bluetooth including temperature and humidity sensor – features
Use the probe to check the indoor climate, for example in offices, production areas or storage facilities. To ensure accurate measurement results, air density compensation is carried out via the integrated absolute pressure measurement.
The readings of the CO2 probe are transmitted to your measuring instrument via Bluetooth, up to a distance of 20 m.
Particularly useful: store individual readings directly in the measuring instrument by pressing the button on the probe. The clearly structured measurement menu for long-term measurement enables the measuring instrument to be operated intuitively. Reading trends are reliably recorded thanks to the convenient input of measurement time and measuring cycle. You can use these trends to evaluate changes in the indoor air quality.
Wireless and space-saving: more applications, less equipment
Endlessly versatile: a universal handle can be connected to all probe heads – so you can master more applications using less equipment and save space. The Bluetooth handle makes it more convenient to carry out your measurement and guarantees less cable clutter in the case.
Or order the cable handle to connect testo probe heads. This is an advantage if Bluetooth signals are not permitted. If the sensors (CO2, humidity, temperature) need to be replaced in the distant future, you can change the probe head.
Intelligent calibration concept
You will get exceptionally accurate measurement results with the digital probe, because the measuring instrument makes measurement uncertainty a thing of the past. You only need to send the probe head in for calibration – so the measuring instrument remains in continuous use.
Areas of application for the CO2 probe with Bluetooth
Use the CO2 probe including temperature and humidity sensor to check the indoor climate (indoor air quality), e.g. in offices, production areas or storage facilities.
The CO2 concentration is a primary indicator of indoor air quality. Poor air quality due to excessive CO2 concentration results in tiredness and lack of concentration, and can even cause illnesses. The CO2 concentration should therefore not normally exceed 1,000 ppm.
Delivery Scope
CO2 probe with Bluetooth including temperature and humidity sensor (consisting of CO2 probe head and Bluetooth handle); 4 x AA batteries, table stand and calibration protocol.
Please do not use the probe in condensing atmospheres. For continuous application in high-humidity ranges
> 80% RH at ≤ 30 °C for > 12 h
> 60% RH at > 30 °C for > 12 h
please contact Testo Service or contact us via the Testo website.
| Temperature - NTC |
|
Measuring range
|
0 to +50 °C
|
|
Accuracy
|
±0.5 °C
|
|
Resolution
|
0.1 °C
|
| Humidity - Capacitive |
|
Measuring range
|
5 to 95 %RH
|
|
Accuracy
|
±3 %RH (10 to 35 %RH)
±2 %RH (35 to 65 %RH)
±3 %RH (65 to 90 %RH)
±5 %RH (Remaining Range)
±0.06 %RH/K (0 to +50 °C)
|
|
Resolution
|
0.1 %RH
|
Please see the additional accuracy information for humidity in the instruction manual.
| Absolute Pressure |
|
Measuring range
|
+700 to +1100 hPa
|
|
Accuracy
|
±3.0 hPa
|
|
Resolution
|
0.1 hPa
|
| Ambient CO₂ |
|
Measuring range
|
0 to 10000 ppm
|
|
Accuracy
|
±(50 ppm + 3 % of mv)
(0 to 5000 ppm)
±(100 ppm + 5 % of mv)
(5001 to 10000 ppm)
|
|
Resolution
|
1 ppm
|
| General technical data |
|
Storage temperature
|
-20 to +60 °C
|
|
Weight
|
195 g
|
|
Dimensions
|
295 x 50 x 40 mm
|
|
Operating temperature
|
-5 to +50 °C
|
|
Length probe shaft
|
130 mm
|
|
Probe head diameter
|
30 mm
|
|
Product colour
|
black/orange
|
|
Battery type
|
4 x type AA batteries
|
|
Battery life
|
21,5 h
|
|
Data transfer
|
Bluetooth®
|
|
Radio range
|
20 m
|
Accessories
Bluetooth® handle for connecting probe heads: transmits readings conveniently via Bluetooth
Order Number: 0554 1111
Cable handle for connecting probe heads: transmits readings via cable
Order Number: 0554 2222
Measuring tripod for IAQ and comfort level measurements, to ensure standard-compliant, secure positioning of measuring instrument and probes including transport bag
Order Number: 0554 1591
Certificates
ISO humidity calibration certificate; with 2 measuring points: 11.3 and 75.3 %RH at +25°C
Order Number: 0520 0006
ISO temperature calibration certificate for air/immersion probes; with 1 measuring point: 0 °C
Order Number: 0520 0062
ISO CO2 calibration certificate; with 3 measuring points: 0 / 1,000 / 5,000 ppm
Order Number: 0520 0033
ISO calibration certificate for pressure; calibration at 3 measuring points, distributed over the measuring range of the measuring instrument/probe – accuracy 0.1 to 0.6 % of f.v.
Order Number: 0520 0085
DAkkS pressure calibration certificate; with 5 measuring points distributed over the measuring range, accuracy > 0.6 % of f.v.
Order Number: 0520 0225
DAkkS pressure calibration certificate; with 9 measuring points distributed over the measuring range, accuracy 0.1 to 0.6 % of f.v.
Order Number: 0520 0215
ISO pressure calibration certificate; with 5 measuring points distributed over the measuring range; accuracy > 0.6 % of f.v.
Order Number: 0520 0005
Sensor heads
16 mm vane probe head including temperature sensor; for attachment to extendable telescope for air velocity probes with universal handle – measuring range +0.6 to +50 m/s, -10 to +70 °C
Order Number: 0635 9570
High-precision 100 mm vane probe head including temperature sensor: for attachment to extendable telescope for air velocity probes with universal handle or to a universal Bluetooth® or cable handle – measuring range +0.1 to +15 m/s, -20 to +70 °C
Order Number: 0635 9370
100 mm vane probe head: for attachment to extendable telescope for air velocity probes with universal handle or to universal Bluetooth® or cable handle – measuring range +0.3 to +35 m/s, -20 to +70 °C
Order Number: 0635 9430
Hot wire probe head including temperature and humidity sensor: for attachment to extendable telescope for air velocity probes with universal handle – measuring range 0 to +50 m/s, -20 to +70 °C, 5 to 95% RH
Order Number: 0635 1570
Humidity/temperature probe head: for attachment to universal Bluetooth® or cable handle – accuracy ±2% RH / ±0.5 °C, measuring range 0 to 100% RH / -20 to +70 °C
Order Number: 0636 9730
High-precision humidity/temperature probe head: for attachment to a universal Bluetooth® or cable handle – accuracy: ±(0.6% RH + 0.7 % of m.v.) (0 to 90% RH) / ±0.3 °C (+15 to +30 °C)
Order Number: 0636 9770
CO₂ probe head including temperature and humidity sensor: for attachment to universal Bluetooth® or cable handle – measuring range 0 to 10,000 ppm, -10 to +50 °C, 5 to 95% RH
Order Number: 0632 1550
CO probe head: for attachment to universal Bluetooth® or cable handle – measuring range 0 to 500 ppm
Order Number: 0632 1270
