testo 835-T2 - Infrared thermometer

Order-Nr. 0560 8352
  • Extended temperature range for reliable measurements up to 1 500 °C

  • IR measurements from a safe distance; precise measuring of moving objects

  • Memory for up to 200 readings; easy analysis with free-to-download software

  • 4-point-laser and 50:1 optics for precise measurements over greater distances

The testo 835 T2 infrared thermometer reveals just what it’s made of long after other infrared thermometers have given up. The testo 835 T2 allows you to measure temperatures up to 1 500 °C and moving objects safely and reliably.

Thông tin sản phẩm
  • Chi tiết sản phẩm
  • Thông số kỹ thuật
  • Phụ kiện
  • Download

Product Description

Ideal for use in the glass, ceramics or the metal industry: the testo 835-T2 high temperature infrared thermometer is the ideal professional tool for a wide variety of thermal applications in the high temperature range. The testo 835-T2 has an extremely wide temperature range which allows you to carry out thermal measurements up to 1 500 °C - and all from a safe distance. It doesn’t matter whether the objects are small, hard to reach, moving or very hot. Thanks to the leading-edge technology tucked away inside, the testo 835-T2 allows you to measure the temperature in all four cases quickly and safely.

  • The 4-point laser clearly indicates the measuring area and prevents incorrect measurements

  • The 50:1 optics allow you to carry out measurements from a long distance and still obtain excellent results (distance 5 m = 10 cm measuring spot)

  • The integrated degree of emission table enables you to select the correct degree of emission of the measured surface

  • The backlit display allows you to use your infrared thermometer in all lighting conditions

The testo 835-T2 also allows you to carry out contact temperature measurements. The thermometer is equipped with a connecting point for a wide range of optional temperature sensors. The temperature sensor can also be used to automatically measure the degree of emission of a particular surface. This makes it easier to carry out subsequent infrared measurements.

There is also a wide range of optional accessories - including a tripod and a robust carry case – that allow you to customize your testo 835-T2 infrared thermometer to suit your needs.

For easy analysis and easy use

The testo 835-T2 comes with an easy-to-follow menu, self-explanatory icons and a user-friendly joystick. Your infrared thermometer can be used to create different measuring sites or save up to 200 readings while additional features including min/max values, adjustable thresholds and visual and acoustic alarms which are triggered when thresholds have been exceeded make work more efficient and life easier. The free-to-download software provides you with a quick and convenient means of analyzing your measuring data.

Delivery Scope

testo 835-T2 high temperature infrared thermometer, 4-point laser marking, measuring data administration, batteries, calibration certificate.

Temperature - TC Type K (NiCr-Ni)

Measuring range

-50 to +1000 °C

Accuracy

±(0.5 °C + 0.5 % of mv)

Resolution

0.1 °C



Temperature - Infrared

Measuring range

-10 to +1500 °C

Accuracy

±2.0 °C or ±1 % of mv

Infrared resolution

0.1 °C (-10.0 to +999.9 °C)

1 °C (+1000.0 to +1500.0 °C)



General technical data

Dimensions

193 x 166 x 63 mm

Operating temperature

-20 to +50 °C

Housing

ABS + PC

Laser spot

on / off

Emissivity table

20 values

Standards

EN 61326-1:2006

Alarmsignal

audible; Optical

Auto-off backlight

30 s*

Auto-off instrument

120 s*

Battery type

3 batteries type AA (or USB operating with PC-Software)

Battery life

25 h (typical 25°C without laser and backlight) 10 h (typical 25°C without backlight)

Display type

Dot Matrix

Memory

200 measuring values

Storage temperature

-30 to +50 °C

Weight

514 g

Bracket

Bracket

Order Number: 0440 0950


Connection cable

USB connection cable, instrument-PC

Order Number: 0449 0047


Silicone heat paste

Silicone heat paste (14g), Tmax = +260°C

Order Number: 0554 0004


Adhesive tape, e.g. for reflective surfaces

Emission tape for measurements on reflective surfaces (roll, length: 10 m, width: 25 mm)

Order Number: 0554 0051


PC Software testo EasyClimate

Free download: PC software testo EasyClimate

Order Number: 0501 0485


testo 0516 8451 case

Cases

Order Number: 0516 8451


Calibration certificate

ISO calibration certificate for temperature (infrared) for infrared measuring instruments; calibration at 3 measuring points: +60 / +120 / +180 °C

Order Number: 0520 0002


Calibration certificate

ISO temperature calibration certificate for air/immersion probes; with 3 measuring points: 0 / +150 / +300 °C

Order Number: 0520 0021


Calibration certificate

ISO calibration certificate for temperature for infrared measuring instruments/probes; calibration at 3 measuring points: -18 / 0 /+ 60 °C

Order Number: 0520 0401
