testo 835-H1 - Infrared thermometer plus moisture measuring

Order-Nr. 0560 8353
  • Measure temperature, moisture and dew point with only one device

  • Calculate the surface moisture content

  • Easy and comfortable to use: easy-to-follow menu guide, can save up to 200 readings, data analysis with free-to-download software

  • Four-Point-Laser and 50:1 Optics for precise measurements even over long distances

Non-contact temperature and moisture measurements – with only one device. The testo 835-H1 infrared thermometer not only measures the temperature but has an intergrated moisture sensor that allows you to measure moisture too.

Thông tin sản phẩm
  • Chi tiết sản phẩm
  • Thông số kỹ thuật
  • Phụ kiện
  • Download

Product Description

Perform temperature and moisture measurements on walls, monitor and check air conditioning and ventilation systems, service and inspect industrial systems, ensure that constantly high levels of quality in production processes are maintained: the testo 835-H1 is the ideal all-round device for a wide range of industrial and commercial applications.

What the testo 835-H1 infrared thermometer plus moisture measuring can do

  • Measure the surface temperature and relative humidity and check the dew point and surface moisture

  • Help to detect mold in buildings before it’s too late

  • Carry out measurements on small, moving or hard-to-reach objects accurately and safely

Benefit from state-of-the-art technology and easy handling

  • 4-Point-Laser: shows the exact measuring zone, effectively preventing wrong measurements

  • 50:1 optics that provide you with excellent surface temperature measurements even over greater distances (distance 5 m = 10 cm measurement spot)

  • Adjustable degree of emission for measuring a wide variety of different surfaces

  • Connectivity for temperature sensors: for additional contact measurements for materials with low degree of emission possible – simply connect your optionally available temperature sensor

  • Easy-to-use, easy-to-follow menu guide thanks to icons and joystick

  • Generate measuring points and save up to 200 measurements

  • Define individual alarm thresholds, acoustic and optical alarm

  • Show min/max values

  • Backlit display

Delivery Scope

testo 835-H1 infrared thermometer plus moisture measuring function and 4-Point laser marking, measurement data management, moisture module, batteries, calibration protocol.

Temperature - TC Type K (NiCr-Ni)

Measuring range

-50 to +600 °C

Accuracy

±(0.5 °C + 0.5 % of mv)

Resolution

0.1 °C



Temperature - Infrared

Measuring range

-30 to +600 °C

Accuracy

±2.5 °C (-30.0 to -20.1 °C)

±1.5 °C (-20.0 to -0.1 °C)

±1.0 °C (0.0 to +99.9 °C)

±1 % of mv (Remaining Range)

Infrared resolution

0.1 °C



Humidity - Capacitive

Measuring range

0 to 100 %RH

Accuracy

±2 %RH

±0.5 °C

Resolution

0.1 °C

0.1 %RH

0.1 °Ctd



General technical data

Dimensions

193 x 166 x 63 mm

Operating temperature

-20 to +50 °C

Product-/housing material

ABS + PC

Laser spot

on / off

Emissivity table

20 values

Standards

EN 61326-1:2006

Alarm function

audible; Optical

Auto-off backlight

30 s*

Auto-off instrument

120 s*

Battery type

3 batteries type AA (or USB operating with PC-Software)

Battery life

25 h (typical 25°C without laser and backlight) 10 h (typical 25°C without backlight)

Display type

Dot Matrix

Memory

200 measuring values

Storage temperature

-30 to +50 °C

Weight

514 g

*disabled for continuous measurement and USB connection

Bracket

Bracket

Order Number: 0440 0950


Connection cable

USB connection cable, instrument-PC

Order Number: 0449 0047


Silicone heat paste

Silicone heat paste (14g), Tmax = +260°C

Order Number: 0554 0004


Adhesive tape, e.g. for reflective surfaces

Emission tape for measurements on reflective surfaces (roll, length: 10 m, width: 25 mm)

Order Number: 0554 0051


testo 0516 8451 case

Order Number: 0516 8451


Calibration certificate

ISO calibration certificate for temperature (infrared) for infrared measuring instruments; calibration at 3 measuring points: +60 / +120 / +180 °C

Order Number: 0520 0002


Calibration certificate

ISO temperature calibration certificate for air/immersion probes; with 3 measuring points: 0 / +150 / +300 °C

Order Number: 0520 0021


Calibration certificate

ISO calibration certificate for temperature for infrared measuring instruments/probes; calibration at 3 measuring points: -18 / 0 /+ 60 °C

Order Number: 0520 0401
