testo 400 IAQ and comfort kit with tripod

Order-Nr. 0563 0401

Standard-compliant determination of the comfort level: PMV and PPD as well as draught and turbulence as per EN ISO 7730 and ASHRAE 55
Monitor the indoor air quality: Determination of CO₂ concentration, humidity, air temperature and turbulence in workplaces, including long-term measurements
Smart, intuitive measurement programs, complete your measurement with full documentation on site at the customer’s premises or carry out further analysis using the testo DataControl measurement data management and analysis software
In the kit: testo 400 universal IAQ instrument, CO₂ probe (with Bluetooth^® handle), turbulence probe with cable, globe thermometer (Ø 150 mm) with cable, measuring tripod with bag, case

Product Information

Product Detail
Product Tech
Accessory
Download

Product Description

Ideal kit for IAQ professionals, with a focus on indoor air quality and comfort level. You will receive the testo 400 universal IAQ measuring instrument with intuitive measurement menus, one CO₂ probe (with Bluetooth^® handle), one turbulence probe and one globe thermometer Ø 150 mm (both with fixed cable). Use the measuring tripod to ensure standard-compliant positioning of the probes. In combination with the IAQ data logger, which is available to order separately, long-term measurements up to 2 weeks can be recorded, even without the IAQ measuring instrument.

testo 400 - Universal IAQ instrument

Order-Nr. 0560 0400

Temperature - NTC
Measuring range	-40 to +150 °C
Accuracy	±0.2 °C ±1 Digit (-25 to +74.9 °C) ±0.4 °C ±1 Digit (-40 to -25.1 °C) ±0.4 °C ±1 Digit (+75 to +99.9 °C) ±0.5 % of mv ±1 Digit (Remaining Range)
Resolution	0.1 °C

Temperature - NTC

Measuring range

-40 to +150 °C

Accuracy

±0.2 °C ±1 Digit (-25 to +74.9 °C)

±0.4 °C ±1 Digit (-40 to -25.1 °C)

±0.4 °C ±1 Digit (+75 to +99.9 °C)

±0.5 % of mv ±1 Digit (Remaining Range)

Resolution

0.1 °C

Temperature - TC Type K (NiCr-Ni)
Measuring range	-200 to +1370 °C
Accuracy	±(0.3 °C + 0.1 % of mv) ±1 Digit
Resolution	0.1 °C

Differential pressure (internal sensor) - Piezoresistive
Measuring range	-100 to +200 hPa
Accuracy	±(0.3 Pa + 1 % of mv) ±1 Digit (0 to 25 hPa) ±(0.1 hPa + 1.5 % of mv) ±1 Digit (25.001 to 200 hPa)
Resolution	0.001 hPa

Differential pressure (internal sensor) - Piezoresistive

Measuring range

-100 to +200 hPa

Accuracy

±(0.3 Pa + 1 % of mv) ±1 Digit (0 to 25 hPa)

±(0.1 hPa + 1.5 % of mv) ±1 Digit (25.001 to 200 hPa)

Resolution

0.001 hPa

Absolute Pressure (internal sensor and external probe)
Measuring range	700 to 1100 hPa
Accuracy	±3 hPa
Resolution	0.1 hPa

General technical data
Weight	510 g (instrument)
Dimensions	210 x 95 x 39 mm ((LxWxH))
Operating temperature	-5 to +45 °C
Product-/housing material	Plastic
Protection class	IP40
Connectable probes	4 x digital Bluetooth® probe or testo Smart Probe; 2 x digital probe with fixed cable or temperature probe NTC with fixed cable (via Testo Universal Connector - TUC); 2 x temperature probe TC type K with fixed cable
Product colour	black/orange
Camera image size	Main camera: 8.0 MP; Front camera: 5.0 MP
Battery life	approx. 10 hrs continuous operation
Display type	5.0" touch display, HD 1280*720 pixels, IPS (160 k)
Power supply	Rechargeable li-ion battery (5550 mAh)
Interface	Bluetooth®; USB; WLAN
Memory	2 GB; 1,000,000 measuring values
Storage temperature	-20 to +60 °C

*TUC connection (Testo Universal Connector): For the connection of fixed cable digital probes and NTC probes.

CO₂ probe (digital) - with Bluetooth^® including temperature and humidity sensor

Order-Nr. 0632 1551

Temperature - NTC
Measuring range	0 to +50 °C
Accuracy	±0.5 °C
Resolution	0.1 °C

Humidity - Capacitive
Measuring range	5 to 95 %RH
Accuracy	±3 %RH (10 to 35 %RH) ±2 %RH (35 to 65 %RH) ±3 %RH (65 to 90 %RH) ±5 %RH (Remaining Range) ±0.06 %RH/K (0 to +50 °C)
Resolution	0.1 %RH

Humidity - Capacitive

Measuring range

5 to 95 %RH

Accuracy

±3 %RH (10 to 35 %RH)

±2 %RH (35 to 65 %RH)

±3 %RH (65 to 90 %RH)

±5 %RH (Remaining Range)

±0.06 %RH/K (0 to +50 °C)

Resolution

0.1 %RH

Please see the additional accuracy information for humidity in the instruction manual.

Absolute Pressure
Measuring range	+700 to +1100 hPa
Accuracy	±3.0 hPa
Resolution	0.1 hPa

Ambient CO₂
Measuring range	0 to 10000 ppm
Accuracy	±(50 ppm + 3 % of mv) (0 to 5000 ppm) ±(100 ppm + 5 % of mv) (5001 to 10000 ppm)
Resolution	1 ppm

Ambient CO₂

Measuring range

0 to 10000 ppm

Accuracy

±(50 ppm + 3 % of mv)

(0 to 5000 ppm)

±(100 ppm + 5 % of mv)

(5001 to 10000 ppm)

Resolution

1 ppm

General technical data
Storage temperature	-20 to +60 °C
Weight	195 g
Dimensions	295 x 50 x 40 mm
Operating temperature	-5 to +50 °C
Length probe shaft	130 mm
Probe head diameter	30 mm
Product colour	black/orange
Battery type	4 x type AA batteries
Battery life	21,5 h
Data transfer	Bluetooth®
Radio range	20 m

Turbulence probe (digital) - wired

Order-Nr. 0628 0152

Temperature - NTC
Measuring range	0 to +50 °C
Accuracy	±0.5 °C
Resolution	0.1 °C

Absolute Pressure
Measuring range	+700 to +1100 hPa
Accuracy	±3.0 hPa
Resolution	0.1 hPa

Velocity - Hot wire
Measuring range	0 to 5 m/s
Accuracy	±(0.03 m/s + 4 % of mv)
Resolution	0.01 m/s

General technical data
Storage temperature	-20 to +60 °C
Weight	250 g
Dimensions	400 x 90 x 90 mm
Operating temperature	0 to +50 °C
Cable length	1.4 m
Probe head diameter	820 mm
Product colour	black/orange
Standards	EN ISO 7730 / ASHRAE 55

Globe thermometer (TC type K) - for radiant heat

Order-Nr. 0602 0743

Temperature - TC Type K (NiCr-Ni)
Measuring range	0 to +120 °C
Accuracy	Class 1 ¹⁾

1) According to standard EN 60584-2, the accuracy of Class 1 refers to -40 to +1000 °C (Type K), Class 2 to -40 to +1200 °C (Type K), Class 3 to -200 to +40 °C (Type K).

General technical data
Weight	385 g
Dimensions	250 x 150 x 150 mm
Cable length	1.4 m
Emissivity	0,95
Probe head diameter	150 mm
Product colour	Black

Measuring tripod for IAQ and comfort level measurements - to ensure standard-compliant positioning of the probes

Order-Nr. 0554 1591

General technical data
Weight	5500 g
Dimensions	730 x 220 x 245 mm (LxWxH)
Product colour	Black

Transport case for IAQ and comfort level measurements

Order-Nr. 0516 2400

General technical data
Weight	3250 g
Dimensions	520 x 410 x 210 mm LxWxH
Product-/housing material	Plastic
Product colour	Black

IAQ data logger for long-term measurements

IAQ data logger for long-term measurements

Order Number: 0577 0400

Measuring tripod for IAQ and comfort level measurements

Measuring tripod for IAQ and comfort level measurements, to ensure standard-compliant, secure positioning of measuring instrument and probes including transport bag

Order Number: 0554 1591

Transport case for air flow measurements

Transport case for air flow measurements

Order Number: 0516 1400

Transport case for air flow measurements

Transport case for IAQ and comfort level measurements

Order Number: 0516 2400

Universal cable handle for connecting probe heads

Cable handle for connecting probe heads: transmits readings via cable

Order Number: 0554 2222

Universal Bluetooth® handle for connecting probe heads

Bluetooth^® handle for connecting probe heads: transmits readings conveniently via Bluetooth

Order Number: 0554 1111

USB mains unit

USB mains unit, including cable

Order Number: 0554 1106

Connection hose, silicone - max. load capacity up to 700 hPa (mbar)

Order Number: 0554 0440

Connection hose

Connection hose silicone-free for differential pressure measurement, length 5 m, load up to maximum 700 hPa, (mbar)

Order Number: 0554 0453

Calibration certificate

ISO pressure calibration certificate; with 5 measuring points distributed over the measuring range; accuracy > 0.6 % of f.v.

Order Number: 0520 0005

Calibration certificate

ISO pressure calibration certificate; with 5 measuring points distributed over the measuring range, accuracy 0.1 to 0.6 % of f.v.

Order Number: 0520 0025

DAkkS pressure calibration certificate; with 5 measuring points distributed over the measuring range, accuracy > 0.6 % of f.v.

Order Number: 0520 0225

Calibration certificate

ISO CO2 calibration certificate; with 3 measuring points: 0 / 1,000 / 5,000 ppm

Order Number: 0520 0033

Calibration certificate

ISO humidity calibration certificate; with 2 measuring points: 11.3 and 75.3 %RH at +25°C

Order Number: 0520 0006

Calibration certificate

ISO temperature calibration certificate for air/immersion probes; with 1 measuring point: 0 °C

Order Number: 0520 0062

Calibration certificate

ISO calibration certificate for pressure; calibration at 3 measuring points, distributed over the measuring range of the measuring instrument/probe – accuracy 0.1 to 0.6 % of f.v.

Order Number: 0520 0085

Calibration certificate

DAkkS pressure calibration certificate; with 9 measuring points distributed over the measuring range, accuracy 0.1 to 0.6 % of f.v.

Order Number: 0520 0215

Calibration certificate

ISO flow calibration certificate for hot wire and vane anemometers; with 4 measuring points: 0.3 / 0.5 / 0.8 / 1.5 m/s

Order Number: 0520 0024

Calibration certificate

DAkkS flow calibration certificate for hot wire and vane anemometers; with 5 measuring points: 0.1 / 0.2 / 0.5 / 0.8 / 1 m/s

Order Number: 0520 0224

Calibration certificate

ISO temperature calibration certificate for air/immersion probes; with 2 measuring points: 0 / +60 °C

Order Number: 0520 0042

Calibration certificate

ISO temperature calibration certificate for air/immersion probes; with 1 measuring point: +60 °C

Order Number: 0520 0063

16 mm vane probe head including temperature sensor

16 mm vane probe head including temperature sensor; for attachment to extendable telescope for air velocity probes with universal handle – measuring range +0.6 to +50 m/s, -10 to +70 °C

Order Number: 0635 9570

High-precision 100 mm vane probe head including temperature sensor

High-precision 100 mm vane probe head including temperature sensor: for attachment to extendable telescope for air velocity probes with universal handle or to a universal Bluetooth^® or cable handle – measuring range +0.1 to +15 m/s, -20 to +70 °C

Order Number: 0635 9370

100 mm vane probe head

100 mm vane probe head: for attachment to extendable telescope for air velocity probes with universal handle or to universal Bluetooth^® or cable handle – measuring range +0.3 to +35 m/s, -20 to +70 °C

Order Number: 0635 9430

Hot wire probe head including temperature and humidity sensor

Hot wire probe head including temperature and humidity sensor: for attachment to extendable telescope for air velocity probes with universal handle – measuring range 0 to +50 m/s, -20 to +70 °C, 5 to 95% RH

Order Number: 0635 1570

Humidity/temperature probe head

Humidity/temperature probe head: for attachment to universal Bluetooth^® or cable handle – accuracy ±2% RH / ±0.5 °C, measuring range 0 to 100% RH / -20 to +70 °C

Order Number: 0636 9730

High-precision humidity/temperature probe head

High-precision humidity/temperature probe head: for attachment to a universal Bluetooth^® or cable handle – accuracy: ±(0.6% RH + 0.7 % of m.v.) (0 to 90% RH) / ±0.3 °C (+15 to +30 °C)

Order Number: 0636 9770

CO2 probe head including temperature and humidity sensor

CO₂ probe head including temperature and humidity sensor: for attachment to universal Bluetooth^® or cable handle – measuring range 0 to 10,000 ppm, -10 to +50 °C, 5 to 95% RH

Order Number: 0632 1550

CO probe head

CO probe head: for attachment to universal Bluetooth^® or cable handle – measuring range 0 to 500 ppm

Order Number: 0632 1270
